POWER
|
|
AC adapter input 100-240V ~ 50/60Hz 0.4A
|
|
AC adapter output 12V ? 1.2A
|
|
HARDWARE FEATURES
|
|
Processor Quad-core CPU
|
|
Interface 2 Gigabit Ethernet Ports (WAN/LAN auto-sensing) per Deco unit
|
|
Button 1 Reset button on the underside
|
|
External Power Supply 12 V/1.2 A
|
|
Flash 16 MB
|
|
SDRAM 128 MB
|
|
Dimensions ?3.6 in. x 7.5 in. (?90.7 mm x 190 mm)
|
|
Antenna Type 2 internal dual-band antennas per Deco unit
|
|
Bluetooth version 4.2 and above
|
|
WIRELESS FEATURES
|
|
Wireless Standards IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz
|
|
Frequency 2.4 GHz and 5 GHz
|
|
Signal Rate 300 Mbps on 2.4 GHz
|
|
867 Mbps on 5 GHz
|
|
Transmit Power FCC:
|
<30 dBm
|
|
CE:
|
<20 dBm (2.4 GHz)
|
|
<23 dBm (5 GHz)
|
|
Wireless Security WPA-PSK/WPA2-PSK
|
|
Advanced Functions ? Router/ Access Point Mode
|
|
? Optional Ethernet Backhaul
|
|
? Guest network
|
|
? TP-Link Mesh Technology:
|
|
MU-MIMO
|
|
Auto Path Selection
|
|
Self-Healing
|
|
AP Steering
|
|
Band Steering
|
|
Beamforming
|
|
SOFTWARE FEATURES
|
|
Quality of Service WMM
|
|
IPv6 Support
|
|
WAN Type Dynamic IP/Static IP/PPPoE
|
|
Management Local Management, Remote Management
|
|
DHCP Server, Client
|
|
Port Forwarding Support
|
|
Access Control Blacklist
|
|
Firewall Security SPI Firewall
|
|
Protocols Supports IPv4 and IPv6
|
|
Advanced Features Parental Controls
|
|
Quality of Service
|
|
Advanced Functions Speedtest
|
|
Monthly Usage Reports
|
|
Auto FW Update
|
|
Expand Wi-Fi by adding more Deco units
|
|
Guest Network 2.4 GHz guest network x 1
|
|
5 GHz guest network x 1
|
|
Beamforming Support
|
|
APP Easy setup via Deco App
|
|
OTHERS
|
|
Certification CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS
|
|
Package Contents ? Deco M4 (3-pack):
|
|
3 Deco units
|
|
1 RJ45 Ethernet Cable
|
|
3 power adapters
|
|
1 quick installation guide
|
|
? Deco M4 (2-pack):
|
|
2 Deco units
|
|
1 RJ45 Ethernet Cable
|
|
2 power adapters
|
|
1 quick installation guide
|
|
? Deco M4 (1-pack):
|
|
1 Deco unit
|
|
1 RJ45 Ethernet Cable
|
|
1 power adapter
|
|
1 quick installation guide
|
|
Smartphone/Tablet Requirements iOS 9.0 or later
|
|
Android 4.3 or later
|
|
Environment Operating Temperature:
|
0?~40? (32?~104?)
|
|
Storage Temperature:
|
-40?~70? (-40?~158?)
|
|
Operating Humidity:
|
10%~90% non-condensing
|
|
Storage Humidity:
|
5%~90% non-condensing
|
