Chipset:
|
AMD B550
|
|
Rozměrový formát:
|
Formát Micro-ATX (244 mm x 244 mm)
|
|
Podpora pro procesory:
|
3rd Gen AMD Ryzen™ processors, and future AMD Ryzen™ processors with BIOS update
|
|
Patice procesoru:
|
AM4
|
|
Pozice na paměti:
|
4x DDR4
|
|
Podpora pro paměti:
|
|
|
•Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
|
|
•Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE
|
|
Max.velikost operační paměti:
|
128 GB
|
|
Podpora pro paměti typu:
|
DDR4
|
|
•Dual channel memory architecture
|
|
•Supports non-ECC UDIMM memory
|
|
•Supports ECC UDIMM memory
|
|
•Supports un-buffered memory
|
|
Grafická karta:
|
na základě procesoru
|
|
•1x VGA port, supports resolution of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz
|
|
•1x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz
|
|
•1x HDMI port, supports a maximum resolution of 4096x2160 @24Hz
|
|
Zvuková karta:
|
|
|
•Realtek® ALC892 Codec
|
|
Síťová karta:
|
|
|
•1x Realtek® 8111HN Gigabit LAN controller
|
|
•Intel® Wireless-AC 3168
|
|
•Bluetooth 4.2
|
|
RAID řadič:
|
|
|
•Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
|
|
•Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
|
|
Rozšiřující sloty:
|
|
|
•1x PCIe 4.0/ 3.0 x16 slot (PCI_E1)
|
|
•2x PCIe 3.0 x1 slots
|
|
SATA:
|
|
|
•4x SATA 6Gb/s ports
|
|
M.2:
|
|
|
•2x M.2 slots (Key M)
|
|
USB:
|
|
|
•zadní USB porty ( celkem 6 )
|
|
•2x USB 2.0 ports
|
|
•4x USB 3.2 Gen 1 5Gbps Type-A ports
|
|
•přední USB porty ( celkem 7 )
|
|
•1x USB 3.2 Gen 1 5Gbps Type-C port
|
|
•2x USB 3.2 Gen 1 5Gbps ports
|
|
•4x USB 2.0 ports
|
|
Interní porty:
|
|
|
•1x 24-pin ATX main power connector
|
|
•1x 8-pin ATX 12V power connector
|
|
•4x SATA 6Gb/s connectors
|
|
•2x M.2 slots (M-Key)
|
|
•1x USB 3.2 Gen 1 5Gbps Type-C port
|
|
•1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
|
|
•2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
|
|
•1x 4-pin CPU fan connector
|
|
•1x 4-pin water-pump fan connector
|
|
•3x 4-pin system fan connectors
|
|
•1x Front panel audio connector
|
|
•2x System panel connectors
|
|
•1x Serial port connector
|
|
•1x Chassis Intrusion connector
|
|
•2x 4-pin RGB LED connectors
|
|
•2x 3-pin RAINBOW LED connectors
|
|
•1x TPM module connector
|
|
•1x Clear CMOS jumper
|
|
Externí porty:
|
|
|
•VGA
|
|
•PS/2 Keyboard / Mouse
|
|
•1x LAN
|
|
•Flash BIOS Button
|
|
•DisplayPort
|
|
•HDMI
|
|
•2x USB 2.0
|
|
•4x USB 3.2 Gen 1 5Gbps Type-A
|
|
•Wi-Fi Antenna connectors
|
|
•3x Audio jacks
|
