Chipset
|
|
AMD B550
|
|
Memory
|
|
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
|
|
3rd Gen AMD Ryzen™ Processors:
|
|
Support for DDR4 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules
|
|
New Generation AMD Ryzen™ with Radeon™ Graphics processors:
|
|
Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules
|
|
Dual channel memory architecture
|
|
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
|
|
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
|
|
Support for Extreme Memory Profile (XMP) memory modules
|
|
(Please refer "Memory Support List" for more information.)
|
|
Onboard Graphics
|
|
Integrated in the New Generation AMD Ryzen™ with Radeon™ Graphics processors:
|
|
1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz
|
* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.
|
|
1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
|
* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
|
|
Maximum shared memory of 16 GB
|
|
Audio
|
|
Realtek® ALC1200 codec
|
|
High Definition Audio
|
|
2/4/5.1/7.1-channel
|
|
Support for S/PDIF Out
|
|
LAN
|
|
Realtek® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
|
|
Expansion Slots
|
|
1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
|
|
- 3rd Generation AMD Ryzen™ processors support PCIe 4.0 x16 mode
|
|
- New Generation AMD Ryzen™ with Radeon™ Graphics processors support PCIe 3.0 x16 mode
|
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
|
|
1 x PCI Express x16 slot (PCIEX2), integrated in the Chipset:
|
|
- Supporting PCIe 3.0 x2 mode
|
|
1 x PCI Express x16 slot (PCIEX1_2), integrated in the Chipset:
|
|
- Supporting PCIe 3.0 x1 mode
|
|
1 x PCI Express x1 slot (PCIEX1_1), integrated in the Chipset:
|
|
- Supporting PCIe 3.0 x1 mode
|
|
Storage Interface
|
|
1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:
|
|
- 3rd Generation AMD Ryzen™ processors support SATA and PCIe 4.0 x4/x2 SSDs
|
|
- New Generation AMD Ryzen™ with Radeon™ Graphics processors support SATA and PCIe 3.0 x4/x2 SSDs
|
|
1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:
|
|
- Supporting SATA and PCIe 3.0 x4/x2 SSDs
|
|
4 x SATA 6Gb/s connectors, integrated in the Chipset:
|
|
- Support for RAID 0, RAID 1, and RAID 10
|
|
USB
|
|
CPU:
|
|
2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
|
|
2 x USB 3.2 Gen 1 ports on the back panel
|
|
Chipset:
|
|
2 x USB 3.2 Gen 1 ports on the back panel
|
|
2 x USB 3.2 Gen 1 ports available through the internal USB header
|
|
2 x USB 2.0/1.1 ports on the back panel
|
|
Chipset+USB 2.0 Hub:
|
|
4 x USB 2.0/1.1 ports available through the internal USB headers
|
|
Internal I/O Connectors
|
|
1 x 24-pin ATX main power connector
|
|
1 x 8-pin ATX 12V power connector
|
|
2 x M.2 Socket 3 connectors
|
|
4 x SATA 6Gb/s connectors
|
|
1 x CPU fan header
|
|
1 x water cooling CPU fan header
|
|
3 x system fan headers
|
|
1 x CPU cooler LED strip/RGB LED strip header
|
|
2 x addressable LED strip headers
|
|
2 x RGB LED strip headers
|
|
1 x front panel header
|
|
1 x front panel audio header
|
|
1 x USB 3.2 Gen 1 header
|
|
2 x USB 2.0/1.1 headers
|
|
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
|
|
1 x Clear CMOS jumper
|
|
Back Panel Connectors
|
|
1 x DisplayPort
|
|
1 x HDMI port
|
|
2 x USB 3.2 Gen 2 Type-A ports (red)
|
|
4 x USB 3.2 Gen 1 ports
|
|
2 x USB 2.0/1.1 ports
|
|
1 x Q-Flash Plus button
|
|
1 x RJ-45 port
|
|
1 x optical S/PDIF Out connector
|
|
5 x audio jacks
|
|
I/O Controller
|
|
iTE® I/O Controller Chip
|
|
H/W Monitoring
|
|
Voltage detection
|
|
Temperature detection
|
|
Fan speed detection
|
|
Water cooling flow rate detection
|
|
Overheating warning
|
|
Fan fail warning
|
|
Fan speed control
|
* Whether the fan speed control function is supported will depend on the fan you install.
|
|
BIOS
|
|
1 x 256 Mbit flash
|
|
Use of licensed AMI UEFI BIOS
|
|
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
|
|
Unique Features
|
|
Support for APP Center
|
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
|
|
@BIOS
|
|
EasyTune
|
|
Fast Boot
|
|
Game Boost
|
|
ON/OFF Charge
|
|
RGB Fusion
|
|
Smart Backup
|
|
System Information Viewer
|
|
Support for Q-Flash Plus
|
|
Support for Q-Flash
|
|
Support for Xpress Install
|
|
Bundled Software
|
|
Norton® Internet Security (OEM version)
|
|
Realtek® 8125 Gaming LAN Bandwidth Control Utility
|
|
Operating System
|
|
Support for Windows 10 64-bit
|
|
Form Factor
|
|
ATX Form Factor; 30.5cm x 24.4cm
|
