Chipset:
|
AMD B450
|
|
Rozměrový formát:
|
mATX Form Factor (226 mm x 221 mm)
|
|
Podpora pro procesory:
|
3rd/2nd/1st Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/Athlon™ with Radeon™ Vega Graphics Processors
|
|
Patice procesoru:
|
AM4
|
|
Pozice na paměti:
|
2x DDR4 DIMM
|
|
Podpora pro paměti:
|
4400(O.C)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory
|
|
Max.velikost operační paměti:
|
64 GB
|
|
Podpora pro paměti typu:
|
DDR4
|
|
•Dual Channel Memory Architecture
|
|
•ECC Memory (ECC mode) support varies by CPU
|
|
Grafická karta:
|
|
|
•Integrated Graphics Processor (na základě procesorů 2. a 1. generace AMD s Radeon Grpahics/Athlon)
|
|
Zvuková karta:
|
|
|
•Realtek 7.1-Channel High Definition Audio CODEC
|
|
Síťová karta:
|
|
|
•Realtek® RTL8111H
|
|
Rozšiřující sloty:
|
|
|
•3rd/2nd/1st Gen AMD Ryzen™ Processors
|
|
•1x PCIe 3.0 x16 (x16 mode)
|
|
•2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
|
|
•1x PCIe 3.0 x16 (x8 mode)
|
|
•AMD Athlon™ with Radeon™ Vega Graphics Processors
|
|
•1x PCIe 3.0 x16 (x4 mode)
|
|
•AMD B450 chipset
|
|
•2x PCIe 2.0 x1
|
|
RAID řadič:
|
0, 1, 10
|
|
SATA:
|
|
|
•4x SATA 6Gb/s ports
|
|
M.2:
|
|
|
•1x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
|
|
USB:
|
|
|
•zadní USB porty ( celkem 6 )
|
|
•4x USB 3.2 Gen 1 port(s)(4 x Type-A)
|
|
•2x USB 2.0 port(s)(2 x Type-A)
|
|
•přední USB porty ( celkem 6 )
|
|
•2x USB 3.2 Gen 1 port(s)
|
|
•4x USB 2.0 port(s)
|
|
Interní porty:
|
|
|
•1x CPU Fan connector(s) (1 x 4 -pin)
|
|
•1x Chassis Fan connector(s) (1 x 4 -pin)
|
|
•1x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) (19-pin)
|
|
•2x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
|
|
•1x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
|
|
•1x SPI TPM header
|
|
•1x COM port(s) connector(s)
|
|
•4x SATA 6Gb/s connector(s)
|
|
•1x S/PDIF out header(s)
|
|
•1x 24-pin EATX Power connector(s)
|
|
•1x 8-pin ATX 12V Power connector(s)
|
|
•1x Front panel audio connector(s) (AAFP)
|
|
•1x System panel(s)
|
|
•1x Clear CMOS jumper(s)
|
|
•1x COM port header
|
|
•1x Speaker connector
|
|
Externí porty:
|
|
|
•1x PS/2 keyboard/mouse combo port(s)
|
|
•1x DVI-D
|
|
•1x D-Sub
|
|
•1x HDMI
|
|
•1x LAN (RJ45) port(s)
|
|
•4x USB 3.2 Gen 1 (blue) Type-A
|
|
•2x USB 2.0
|
|
•3x Audio jack(s)
|
|
•1x BIOS FlashBack™ Button(s)
|
|
Obsah balení:
|
|
|
•User's manual
|
|
•I/O Shield
|
|
•2x SATA 6Gb/s cable(s)
|
|
•1x M.2 Anchor
|
|
•1x Supporting DVD
|
|
BIOS:
|
256 Mb Flash ROM, UEFI AMI BIOS
|
