Intel® quad-core processor n100 (up to 3.4 ghz)
|
Supports 1 ddr4 dimm
|
1 dc jack (compatible with the 19v power adapter, 5.5 x 2.5mm dc-in jack)
|
1 pcie 3.0 x4 (x2 mode), 1 m.2 key e for wifi
|
Graphics output options: d-sub, hdmi
|
7.1 ch hd audio (realtek alc897 audio codec)
|
2 sata3, 1 m.2 (pcie gen3x2)
|
4 usb 3.2 gen1 (2 rear, 2 front)
|
Realtek gigabit lan
|
Supports asrock auto driver installer
|
|
Cpu
|
Intel® quad-core processor n100 (up to 3.4 ghz)
|
Supports intel® turbo boost technology
|
|
Memory
|
1 x ddr4 dimm slot
|
Supports ddr4 non-ecc, un-buffered memory up to 3200
|
Supports ecc udimm memory modules (operate in non-ecc mode)
|
Max. capacity of system memory: 32gb
|
|
Graphics
|
Integrated intel® uhd graphics: 24 eus inside (up to 750mhz)
|
1 x hdmi 2.1 tmds compatible, supports hdcp 2.2 and max. resolution up to 4k 60hz
|
1 x d-sub, supports max. resolution up to full hd (1920x1080) 60hz
|
|
Audio
|
7.1 ch hd audio (realtek alc897 audio codec)
|
|
Lan
|
Gigabit lan 10/100/1000 mb/s
|
Realtek 8111h
|
|
Slots
|
1 x pcie 3.0 x4 slot (pcie1), supports x2 mode*
|
1 x m.2 socket (key e), supports type 2230 intel® cnvio (integrated wifi/bt)
|
|
Storage
|
1 x m.2 socket (m2_1, key m), supports type 2280 pcie gen3x2 (16 gb/s) mode*
|
2 x sata3 6.0 gb/s connectors
|
|
Usb
|
4 x usb 3.2 gen1 (2 rear, 2 front)
|
8 x usb 2.0 (4 rear, 4 front)
|
|
Internal connector
|
1 x print port header
|
1 x spi tpm header
|
1 x chassis intrusion and speaker header
|
2 x chassis fan connectors (4-pin)
|
1 x front panel audio connector
|
2 x usb 2.0 headers (support 4 usb 2.0 ports)
|
1 x usb 3.2 gen1 header (supports 2 usb 3.2 gen1 ports)
|
|
Rear panel i/o
|
1 x dc jack (compatible with the 19v power adapter, 5.5 x 2.5mm dc-in jack)
|
2 x antenna mounting points
|
1 x ps/2 mouse/keyboard port
|
1 x serial port: com1
|
1 x d-sub port
|
1 x hdmi port
|
2 x usb 3.2 gen1 ports
|
4 x usb 2.0 ports
|
1 x rj-45 lan port
|
Hd audio jacks: line in / front speaker / microphone
|
|
Software and uefi
|
|
Software
|
Asrock motherboard utility (a-tuning)
|
Asrock xfast lan
|
Uefi
|
Asrock ez mode
|
Asrock full hd uefi
|
Asrock auto driver installer
|
Asrock instant flash
|
|
Accessories
|
1 x user manual
|
1 x i/o shield
|
2 x sata data cables
|
1 x sata power cable
|
2 x screws for m.2 sockets
|
|
Form factor
|
Mini-itx form factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
|
Solid capacitor design
|
|
Os
|
Microsoft® windows® 10 64-bit / 11 64-bit
|
|
Certifications
|
Fcc, ce
|
Erp/eup ready (erp/eup ready power supply is required)
|
|
Bios
|
128mb ami uefi legal bios with gui support
|
|
Unique feature
|
Rock-solid durability
|
2+1+1 power phase ez update
|
Asrock auto driver installer
|
|
