Models
|
|
GS1200-5HP v2
|
|
Description 5-Port Web Managed PoE Gigabit Switch
|
|
Case Metal
|
|
Key Features
|
|
Auto MDI/MDI-X Yes
|
|
Store and Forward Yes
|
|
Full Duplex Capability Yes
|
|
Flow Control Yes
|
|
Hardware
|
|
10/100 Mbps Ethernet Ports -
|
|
10/100/1000 Mbps Ethernet Ports 5
|
|
10/100/1000 Mbps Ethernet PoE+ Ports 4
|
|
Performance
|
|
Switching Capacity 10 Gbps
|
|
MAC Address 2K
|
|
Memory Buffer 128 KB
|
|
Jumbo Frames Up to 9 KB
|
|
System Features
|
|
Web GUI Yes
|
|
802.3x Flow Control Yes
|
|
DHCP Client Yes
|
|
802.1Q VLAN Yes
|
|
WRR Priority QoS Yes
|
|
Port-based QoS Yes
|
|
802.1p CoS Yes
|
|
Broadcast Storm Control Yes
|
|
Loop Detection /Prevention Yes
|
|
IGMP Snooping v1/v2/and v3 Compatitble Yes
|
|
Link Aggregation Yes
|
|
Port Mirroring Yes
|
|
Green Features
|
|
Fanless Yes
|
|
Power Saving by Detecting Link Status & Cable Length Yes
|
|
Power
|
|
Input voltage 55 V/1.3 A
|
|
Power supply External
|
|
Maximum power consumption (watt) 72
|
|
PoE power budget (watt) 60
|
|
Physical Specifications
|
|
Item dimensions (WxDxH) 193 x 84 x 26 mm
|
|
(7.6" x 3.3" x 1.0" )
|
|
Item weight 392g (0.86 lb.)
|
|
Packing dimensions (WxDxH) 210 x 132 x 78 mm
|
|
(8.3" x 5.2" x 3.1")
|
|
Packing weight 950g (2.10 lb.)
|
|
Environmental Specifications
|
|
Operating Temperature
|
|
0°C to 40°C/32°F to 104°F
|
|
Humidity
|
|
10% to 90% (non-condensing)
|
|
Storage Temperature
|
|
-40°C to 70°C/-40°F to 158°F
|
|
Humidity
|
|
10% to 90% (non-condensing)
|
|
Models
|
|
Description
|
|
Case
|
|
Key Features
|
|
Auto MDI/MDI-X
|
|
Store and Forward
|
|
Full Duplex Capability
|
|
Flow Control
|
|
Hardware
|
|
10/100 Mbps Ethernet Ports
|
|
10/100/1000 Mbps Ethernet Ports
|
|
10/100/1000 Mbps Ethernet PoE+ Ports
|
|
Performance
|
|
Switching Capacity
|
|
MAC Address
|
|
Memory Buffer
|
|
Jumbo Frames
|
|
System Features
|
|
Web GUI
|
|
802.3x Flow Control
|
|
DHCP Client
|
|
802.1Q VLAN
|
|
WRR Priority QoS
|
|
Port-based QoS
|
|
802.1p CoS
|
|
Broadcast Storm Control
|
|
Loop Detection /Prevention
|
|
IGMP Snooping v1/v2/and v3 Compatitble
|
|
Link Aggregation
|
|
Port Mirroring
|
|
Green Features
|
|
Fanless
|
|
Power Saving by Detecting Link Status & Cable Length
|
|
Power
|
|
Input voltage
|
|
Power supply
|
|
Maximum power consumption (watt)
|
|
PoE power budget (watt)
|
|
Physical Specifications
|
|
Item dimensions (WxDxH)
|
|
Item weight
|
|
Packing dimensions (WxDxH)
|
|
Packing weight
|
|
Environmental Specifications
|
|
Operating
|
|
Storage
|
|
|
|
|
*All specifications are subject to change without notice.
|
